Standards Met | UL Listed, CE Marked, CSA Certified |
Sensor Technology | Photoelectric |
IP Rating | IP65 - dust tight; water jet protected, IP67 - dust tight; water immersion protected, IP30 - objects >2.5mm; not water protected |
Minimum Operating Temperature | -25 °C |
Maximum Operating Temperature | 55 °C |
Shielding | N/A |
Reverse Polarity Protection | |
Output Type | PNP/NPN |
Thread Size | |
Terminal Type | 4-Pin M12 Connector |
Mounting Type | |
Housing Material | Plastic |
Body Style | Rectangular |
Material Detected | Metal, Plastic - Opaque, Glass - Opaque |
Brand | Schneider Telemecanique |
Detection Type | Diffuse |
Switching Mode | |
Light Source | |
Hazardous Area Certification | |
Maximum Detection Range | 2000 mm |
Minimum Detection Range | 0 mm |
Maximum DC Supply Voltage | 24 V |
Minimum DC Supply Voltage | 12 V |
Electrical Connection | Connector |
Dimensions | |
Length | 77 mm |
Series | XUX |
