Standards Met | UL Listed, CSA Certified, CCC Certified |
Sensor Technology | Inductive |
IP Rating | IP68 - dust tight; water submersion protected |
Minimum Operating Temperature | -25 °C |
Maximum Operating Temperature | 70 °C |
Shielding | Unshielded |
Reverse Polarity Protection | No |
Output Type | NO |
Thread Size | |
Terminal Type | 3-Pin UNF Connector |
Mounting Type | Non-Flush |
Housing Material | Plastic |
Body Style | Rectangular |
Material Detected | Metal |
Brand | Schneider Telemecanique |
Detection Type | |
Switching Mode | |
Light Source | |
Hazardous Area Certification | |
Maximum Detection Range | 25 mm |
Minimum Detection Range | 0 mm |
Maximum AC Supply Voltage | 240 V |
Minimum AC Supply Voltage | 24 V |
Maximum DC Supply Voltage | 240 V |
Minimum DC Supply Voltage | 24 V |
Electrical Connection | Connector |
Dimensions | 40 x 15 x 40 mm |
Length | 40 mm |
Depth | 15 mm |
Height | 40 mm |
Series | |
