| Terminal Type | Screw |
| Minimum Operating Temperature | -40 °C |
| Maximum Operating Temperature | +60 °C |
| Function | Reversing |
| Operational Current | |
| Mounting Style | DIN-Rail |
| Standards/Approvals | EN 60947-5-1, IEC 60335-1, EN 60947-4-1, IEC 60947-4-1, UL 508, CSA C22.2 No 14, IEC 60947-5-1 |
| Width | 90 mm |
| Length | 95 mm |
| Brand | Schneider |
| Auxiliary Contact Configuration | 1 NC, 1 NO |
| Coil Voltage [VAC] | |
| Manufacturer | Schneider |
| Number of Auxiliary Contacts | |
| Contact Voltage Rating [VAC] | 690 |
| Contactor Application | Motor Control, Resistive Load |
| Coil Voltage [VDC] | 12 |
| Interlocking type | Mechanical |
| Power Rating [KVA] | |
| Power Rating [KVAR] | |
| Utilisation category | |
| Control Circuit Voltage Uc | 12 V |
| Pole and Throw Configuration | 3P |
| Contact Current Rating [AC] | 25 |
| Depth | 95 mm |
| Power Rating [kW] | 0.0024 |
| Contact Voltage Rating [VDC] | 300 |
| Number of Poles | 3 |
| Series | LC2D |
| Contact Current Rating [DC] | |
| Normal State Configuration | 3 NO |
