Please note: Some technical details are unavailable for this product

Sensata/Cynergy3 REED RELAY, 24V SPNO, RHODIUM, FLY LEAD

RS Stock No: 1245071

Mfr Part No: DAR72410F-HR/RS

Brand: Sensata/Cynergy3

REED RELAY, 24V SPNO, RHODIUM, FLY LEAD
In stock - 4
£56.39(exc. VAT)
£67.67(inc. VAT)
Buy from RS Online

Technical Specifications

AttributeValue
Standards MetUL
Terminal TypeFlying Lead
Mounting TypePCB
Product TypeReed Relay
Maximum Switching Voltage [AC]1000 V
Operating Time Including Bounce [ms]3 ms
Width [mm]15.8 mm
SeriesDAR
LatchingNo
GTIN
Special Features5kV, 1x1014 Ohms minimum insulation resistance, 7.5kV, Ideal for sensitive test and measurement circuits which require low leakage current losses, High Insulation Resistance, Low Contact Resistance, 10kV or 15kV isolation, PCB or flying leads connections
Contact Resistance [mΩ]50 mOhm
Relay Switching ClassificationGeneral Purpose Relay
Minimum Operating Temperature [°C]-20 °C
Life10^6 (50W Switching) cycles, 10^9 (Dry Switching) cycles
Operating Temperature Range [°C]-20 to 70 °C
Number of Poles1
Dimensions [mm]60 x 15.8 x 18.5 mm
Coil Power [W]50 W
Contact MaterialRhodium
Maximum Operating Temperature [°C]70 °C
Maximum Switching Power DC [W]50 W
Isolation Coil To Contact [kV]17 kV
Depth [mm]15.8 mm
Height [mm]18.5 mm
Length [mm]60 mm
Maximum Switching Voltage [DC]1000 V
Maximum Switching Current DC [A]3 A
Maximum Switching Current AC [A]3 A
Coil Voltage [VDC]24 V
Contact ConfigurationSPST-NO
