Please note: Some technical details are unavailable for this product

Sensata/Cynergy3 SPST N/O 5KV ISOLATION 12V COIL (FLYING

RS Stock No: 1892166

Mfr Part No: DAR71205FU

Brand: Sensata/Cynergy3

SPST N/O 5KV ISOLATION 12V COIL (FLYING
Out of stock
£737.16(exc. VAT)
£884.59(inc. VAT)
Buy from RS Online

Technical Specifications

AttributeValue
Terminal TypeFlying lead
Mounting TypePCB
Standards MetUL
Product TypeReed Relay
Maximum Switching Voltage [AC]1000 V
Operating Time Including Bounce [ms]3 ms
Width [mm]15.8 mm
SeriesDAR
LatchingNo
GTINEAN-13 5059045834953
Special FeaturesChoice of 10kV, PCB or Panel mΩunt, Low Contact Resistance, 7.5kV or 5kV Isolation, Excellent AC Characteristics
Contact Resistance [mΩ]50 mOhm
Relay Switching ClassificationGeneral Purpose Relay
Minimum Operating Temperature [°C]-20 °C
Life10^6 (50W Switching) cycles, 10^9 (Dry Switching) cycles
Operating Temperature Range [°C]-20 to 70 °C
Number of Poles1
Dimensions [mm]60 x 15.8 x 18.5 mm
Coil Power [W]50 W
Contact MaterialRhodium
Maximum Operating Temperature [°C]70 °C
Maximum Switching Power DC [W]50 W
Isolation Coil To Contact [kV]17 kV
Depth [mm]15.8 mm
Height [mm]18.5 mm
Length [mm]60 mm
Maximum Switching Voltage [DC]1000 V
Maximum Switching Current DC [A]3 A
Maximum Switching Current AC [A]3 A
Coil Voltage [VDC]12 V
Contact ConfigurationSPST-NO
