| Standards Met | UR |
| Terminal Type | PCB Pin |
| Mounting Type | PCB |
| Product Type | Reed Relay |
| Maximum Switching Voltage [AC] | 1000 V |
| Operating Time Including Bounce [ms] | 1 ms |
| Width [mm] | 10 mm |
| Series | S8 |
| Latching | No |
| GTIN | |
| Special Features | Isolation Voltage across contacts 4kV or 5kV (dependent on coil voltage), Space saving package |
| Contact Resistance [mΩ] | 150 mOhm |
| Relay Switching Classification | General Purpose Relay |
| Minimum Operating Temperature [°C] | -40 °C |
| Life | 10^7 (100 W) operations, 10^9 (Dry) operations |
| Operating Temperature Range [°C] | -40 to 85 °C |
| Number of Poles | 1 |
| Dimensions [mm] | 30 x 10 x 12 mm |
| Coil Power [W] | 100 W |
| Contact Material | Rhodium |
| Maximum Operating Temperature [°C] | 85 °C |
| Maximum Switching Power DC [W] | 100 W |
| Isolation Coil To Contact [kV] | 7 kV |
| Depth [mm] | 10 mm |
| Height [mm] | 12 mm |
| Length [mm] | 30 mm |
| Maximum Switching Voltage [DC] | 1000 V |
| Maximum Switching Current DC [A] | 1 A |
| Maximum Switching Current AC [A] | 1 A |
| Coil Voltage [VDC] | 12 V |
| Contact Configuration | SPST-NO |
