Technical Reference

Technical Specifications

AttributeValue
Thread Size
Terminal Type6-Pin Q6 Connector
Mounting TypePanel Mount
Housing MaterialPlastic
Body StyleRectangular
Sensor TechnologyPhotoelectric
IP RatingIP65 - dust tight; water jet protected
Minimum Operating Temperature-40 °C
Maximum Operating Temperature60 °C
ShieldingN/A
Reverse Polarity Protection
Output TypeElectrically Isolated Relay
Standards MetUL Certified, CE Marked
Material DetectedMetal, Plastic - Opaque, Glass - Opaque
BrandSick
Detection TypeDiffuse
Switching ModeLight/Dark switching
Light SourceInfrared
Hazardous Area Certification
Maximum Detection Range1600 mm
Minimum Detection Range30 mm
Maximum AC Supply Voltage250 V
Minimum AC Supply Voltage20 V
Maximum DC Supply Voltage250 V
Minimum DC Supply Voltage20 V
Electrical ConnectionConnector
Dimensions24.6 x 80.6 x 54 mm
Length54 mm
Width24.6 mm
Height80.6 mm
SeriesW27-3
