Technical Reference

Technical Specifications

AttributeValue
Mounting TypeNon-flush
Thread SizeM18 x 1
Terminal TypeM12 Connector
Housing MaterialPlastic
Body StyleCylindrical
Supply Voltage10 V to 30 V
Output TypeNPN
Maximum Operating Temperature85
Sensor TechnologyCapacitive
Shielding
Minimum Operating Temperature-30
IP RatingIP68
Reverse Polarity ProtectionYes
ManufacturerSick
Shape
SeriesCM
Depth18
Hazardous Area Certification
Standards/ApprovalsUL Certified, CE
BrandSick
Supply Voltage DC Max30 V
Application
Communication Interface
Sensing Distance12 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length81
Switching Frequency Max0.05 kHz
Dimensions
Electrical ConnectionM12 Connector
