Technical Reference

Technical Specifications

AttributeValue
Supply Voltage10 V to 30 V
Output TypePNP
Maximum Operating Temperature85
Sensor TechnologyCapacitive
Shielding
Minimum Operating Temperature-30
IP RatingIP68
Reverse Polarity ProtectionYes
Mounting TypeFlush
Thread SizeM30 x 1
Terminal TypeM12 Connector
Housing MaterialPlastic
Body StyleCylindrical
ManufacturerSick
Shape
SeriesCM
Depth30
Hazardous Area Certification
Standards/ApprovalsUL Certified, CE
BrandSick
Supply Voltage DC Max30 V
Application
Communication Interface
Sensing Distance16 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length81
Switching Frequency Max0.05 kHz
Dimensions
Electrical ConnectionM12 Connector
