Technical Reference

Technical Specifications

AttributeValue
Supply Voltage10 V to 30 V
Output TypeNPN
Maximum Operating Temperature75
Sensor TechnologyCapacitive
Shielding
Minimum Operating Temperature-25
IP RatingIP67
Reverse Polarity ProtectionYes
Mounting TypeNon-flush
Thread Size
Terminal TypeM12 Connector
Housing MaterialPlastic
Body StyleRectangular
ManufacturerSick
Shape
SeriesCQ
Depth15
Hazardous Area Certification
Standards/ApprovalsUL Certified, CE
BrandSick
Supply Voltage DC Max30 V
Application
Communication Interface
Sensing Distance25 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length69.5
Switching Frequency Max0.05 kHz
Dimensions69.5 x 35 x 15 mm
Width35
Electrical ConnectionM12 Connector
