Technical Reference

Technical Specifications

AttributeValue
Supply Voltage10 V to 36 V
Output TypePNP
Maximum Operating Temperature85
Sensor TechnologyCapacitive
ShieldingUnshielded
Minimum Operating Temperature-30
IP RatingIP69K, IP68
Reverse Polarity ProtectionYes
Mounting TypeNon-flush
Thread SizeM18 x 1
Terminal TypeCable
Housing MaterialPBT
Body StyleCylindrical
ManufacturerSick
Shape
Series
Hazardous Area Certification
Standards/ApprovalsCSA, CE, cULus, EcoLab Certified
BrandSick
Supply Voltage DC Max36 V
Application
Communication Interface
Sensing Distance12 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency50 Hz
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length86
Switching Frequency Max
Dimensions
Width18
Electrical ConnectionCable
