Technical Reference

Technical Specifications

AttributeValue
Thread SizeM18
Terminal Type4-Wire Cable
Mounting TypeFlush
Housing MaterialPlastic
Body StyleBarrel
Standards MetcULus Certified, EcoLab Certified, CE Marked, CSA Certified
Sensor TechnologyCapacitive
IP RatingIP68 - dust tight; water submersion protected, IP69K - dust tight; close-range high-pressure hot water protected
Minimum Operating Temperature-30 °C
Maximum Operating Temperature85 °C
ShieldingUnshielded
Reverse Polarity ProtectionYes
Output TypePNP
Material Detected
BrandSick
Detection Type
Switching Mode
Light Source
Hazardous Area Certification
Maximum Detection Range8 mm
Minimum Detection Range0 mm
Maximum DC Supply Voltage36 V
Minimum DC Supply Voltage10 V
Maximum AC output current200 mA
Electrical ConnectionCable
DimensionsM18 x 86 mm
Length86 mm
SeriesCM
