Technical Reference

Technical Specifications

AttributeValue
Standards Met
Output TypeNO/NC
Maximum Operating Temperature55
Maximum DC Voltage240 V
Minimum Operating Temperature-25
IP RatingIP67
Detection Range12000 mm
Mounting Type
Thread Size
Terminal TypeCable
Housing MaterialPlastic
Body StyleCompact Rectangular
ManufacturerSick
Optical Technology
Detection TypeRetro-reflective
SeriesW250-2
Sensor TypeBlock
Maximum AC Voltage240 V
Light SourceInfrared LED
Maximum Current
Hazardous Area Certification
Switching Mode
BrandSick
Communication Interface
Response Time15 ms
Electrical ConnectionCable
