Technical Reference

Technical Specifications

AttributeValue
Thread Size
Terminal Type
Mounting Type
Housing MaterialPlastic
Body StyleRectangular
Standards MetUL Certified
Sensor TechnologyPhotoelectric
IP RatingIP67 - dust tight; water immersion protected
Minimum Operating Temperature-25 °C
Maximum Operating Temperature55 °C
ShieldingN/A
Reverse Polarity Protection
Output TypePNP
Material DetectedMetal, Plastic - Opaque, Glass - Opaque
BrandSick
Detection TypeRetroreflective
Switching ModeLight/Dark switching
Light SourceLED
Hazardous Area Certification
Maximum Detection Range14000 mm
Minimum Detection Range0 mm
Maximum DC Supply Voltage30 V
Minimum DC Supply Voltage10 V
Electrical ConnectionCable Gland
Dimensions25 x 78 x 63 mm
Length63 mm
Width25 mm
Height78 mm
SeriesW260
