Technical Reference

Technical Specifications

AttributeValue
Standards MetCE Marked
Thread Size
Terminal Type5-Wire 2 m Cable
Mounting Type
Housing MaterialPlastic
Body StyleRectangular
Sensor TechnologyPhotoelectric
IP RatingIP67 - dust tight; water immersion protected, IP66 - dust tight; heavy seas protected
Minimum Operating Temperature-25 °C
Maximum Operating Temperature55 °C
ShieldingN/A
Reverse Polarity Protection
Output TypeElectrically Isolated Relay
Material DetectedMetal, Plastic - Opaque, Glass - Opaque
BrandSick
Detection TypeRetroreflective
Switching ModeLight Switching
Light SourceLED
Hazardous Area Certification
Maximum Detection Range15000 mm
Minimum Detection Range0 mm
Maximum AC Supply Voltage240 V
Minimum AC Supply Voltage24 V
Maximum DC Supply Voltage240 V
Minimum DC Supply Voltage24 V
Electrical ConnectionCable
Dimensions23.5 x 74.5 x 63 mm
Length63 mm
Width23.5 mm
Height74.5 mm
SeriesW280-2
