Technical Reference

Technical Specifications

Output TypeNPN
Maximum Operating Temperature55 °C
Maximum DC Voltage30 V
Minimum Operating Temperature-25 °C
IP RatingIP67
Detection Range7200 mm
Mounting Type
Thread Size
Terminal TypeM12 Connector
Housing MaterialPlastic
Body StyleCylindrical axial
Standards Met
Optical Technology
Detection TypeRetro-reflective
Sensor TypeBarrel
Light SourcePinPoint LED
Maximum Current
Hazardous Area Certification
Switching Mode
Communication Interface
Response Time0.5 ms
Electrical ConnectionM12 Connector
