Technical Reference

Technical Specifications

AttributeValue
Output TypePNP
Maximum Operating Temperature55
Maximum DC Voltage30 V
Minimum Operating Temperature-25
IP RatingIP67
Detection Range
Standards Met
Mounting Type
Thread Size
Terminal Type
Housing MaterialNickel Plated
Body StyleCylindrical
ManufacturerSick
Optical Technology
Detection TypeDiffuse
SeriesGR18S
Sensor TypeCylindrical
Light Source
Maximum Current100 mA
Hazardous Area Certification
Switching ModeDark Switching
BrandSick
Communication Interface
Response Time1 ms
Electrical ConnectionM12 Connector
