Technical Reference

Technical Specifications

AttributeValue
Sensor TechnologyPhotoelectric
IP RatingIP67 - dust tight; water immersion protected
Minimum Operating Temperature-25 °C
Maximum Operating Temperature55 °C
ShieldingN/A
Reverse Polarity Protection
Output TypeNPN
Thread SizeM18
Terminal Type3-Pin M12 Connector
Mounting TypeAxial
Housing MaterialNickel-Plated Brass
Body StyleBarrel
Standards MetUL Certified, CE Marked
Material DetectedMetal, Plastic - Opaque, Glass - Opaque
BrandSick
Detection TypeEnergetic
Switching ModeLight Switching
Light SourceLED
Hazardous Area Certification
Maximum Detection Range115 mm
Minimum Detection Range3 mm
Maximum DC Supply Voltage30 V
Minimum DC Supply Voltage10 V
Electrical ConnectionConnector
Dimensions
Length38.1 mm
Width18 mm
Height18 mm
SeriesGR18S
