Technical Reference

Technical Specifications

AttributeValue
Thread SizeM12
Terminal Type4-Pin M12 Connector
Mounting Type
Housing MaterialNickel-Plated Brass
Body StyleBarrel
Sensor TechnologyPhotoelectric
IP RatingIP67 - dust tight; water immersion protected
Minimum Operating Temperature-25 °C
Maximum Operating Temperature55 °C
ShieldingN/A
Reverse Polarity Protection
Output TypeNPN
Standards MetUL Certified, CE Marked
Material DetectedMetal, Plastic - Opaque, Glass - Opaque
BrandSick
Detection TypeEnergetic
Switching ModeLight/Dark switching
Light SourceLED
Hazardous Area Certification
Maximum Detection Range500 mm
Minimum Detection Range1 mm
Maximum DC Supply Voltage30 V
Minimum DC Supply Voltage10 V
Electrical ConnectionConnector
Dimensions18 x 18 x 69.8 mm
Length69.8 mm
Width18 mm
Height18 mm
SeriesV180-2
