Technical Specifications

AttributeValue
Standards Met
Output TypeAnalogue
Maximum Operating Temperature65 °C
Maximum DC Voltage30 V
Minimum Operating Temperature-30 °C
IP RatingIP65
Detection Range10000 mm
Mounting TypePanel Mount
Thread Size
Terminal TypeConnector M12 - 5 Pin
Housing MaterialPMMA, Die Cast Zinc
Body StyleRectangular
ManufacturerSick
Optical TechnologyPhototransistor
Detection TypeRetro-reflective
SeriesDx50
Sensor TypeBlock
Light SourceLaser Light
Maximum Current100 mA
Hazardous Area Certification
Switching Mode
BrandSick
Communication Interface
Response Time30 ms
Electrical ConnectionM12 5 Pin Connector
