Technical Reference

Technical Specifications

AttributeValue
Standards Met
Output TypeAnalogue
Maximum Operating Temperature65 °C
Maximum DC Voltage30 V
IP RatingIP65
Detection Range10000 mm
Mounting Type
Thread Size
Terminal Type
Housing MaterialDie Cast Zinc
Body StyleRectangular
ManufacturerSick
Optical Technology
Detection TypeDistance
SeriesDx50
Sensor TypeBlock
Light Source
Maximum Current100 mA
Hazardous Area Certification
Switching Mode
BrandSick
Communication Interface
Response Time30 ms
Electrical ConnectionM12 5 Pin Connector
