Fibre Optic Sensor WLL180T-E434

Technical Specifications

Attribute	Value
Mounting Type
Housing Material	Plastic
Supply Voltage	24 V
Output Type	NPN
Maximum Operating Temperature	+55 °C
Minimum Operating Temperature	-25 °C
IP Rating	IP50
Detection Range	18000 mm
Standards Met
Manufacturer	Sick
Detection Type	Through Beam
Depth	71.9 mm
Light Source
Brand	Sick
Communication Interface
Response Time	0.016 ms
Switching Frequency	31200 Hz
Fibre Optic Type	Glass or Plastic
Power Consumption
Length	34.6 mm
Dimensions	34.6 x 10.5 x 71.9 mm
Width	10.5 mm
Electrical Connection	4-Pin Connector
