Technical Reference

Technical Specifications

Standards MetUL Certified, CE Marked
Thread SizeM8
Terminal Type3-Pin M8 Connector
Mounting Type
Housing MaterialMetal
Body StyleFork
Sensor TechnologyOptical
IP RatingIP67 - dust tight; water immersion protected
Minimum Operating Temperature-10 °C
Maximum Operating Temperature60 °C
Reverse Polarity Protection
Output TypeNPN
Material DetectedMetal, Plastic - Opaque, Glass - Opaque
Detection TypeFork Sensor
Switching ModeLight Switching
Light SourceLED
Hazardous Area Certification
Maximum Detection Range30 mm
Minimum Detection Range0 mm
Maximum DC Supply Voltage30 V
Minimum DC Supply Voltage10 V
Electrical ConnectionConnector
Dimensions10 x 50 x 59.5 mm
Length59.5 mm
Width10 mm
Height50 mm
