Technical Specifications

AttributeValue
Mounting TypeFlush
Thread Size
Terminal Type2m Cable, 3-Wire
Housing MaterialStainless Steel
Body StyleCylindrical
Supply Voltage10 V to 30 V
Output TypePNP NO
Maximum Operating Temperature70 °C
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25 °C
IP RatingIP67
Reverse Polarity ProtectionYes
ManufacturerSick
Shape
Series
Hazardous Area Certification
Standards/Approvals
BrandSick
Supply Voltage DC Max30 V
Application
Communication Interface
Sensing Distance1 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current100 mA
Short Circuit Overload ProtectionYes
Length12 mm
Switching Frequency Max8 kHz
Dimensions
Width3 mm
Electrical Connection3-Wire, 2 m Cable
