Technical Reference

Technical Specifications

AttributeValue
Mounting TypeFlush
Thread SizeM4 x 0.5
Terminal Type2m Cable, 3-Wire
Housing MaterialStainless Steel
Body StyleCylindrical
Supply Voltage10 V to 30 V
Output TypePNP NC
Maximum Operating Temperature70 °C
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25 °C
IP RatingIP67
Reverse Polarity ProtectionYes
ManufacturerSick
Shape
Series
Hazardous Area Certification
Standards/Approvals
BrandSick
Supply Voltage DC Max30 V
Application
Communication Interface
Sensing Distance0.6 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current100 mA
Short Circuit Overload ProtectionYes
Length22 mm
Switching Frequency Max5 kHz
Dimensions
Width4 mm
Electrical Connection3-Wire, 2 m Cable
