Technical Reference

Technical Specifications

AttributeValue
Supply Voltage10 V to 30 V
Output TypePNP NC
Maximum Operating Temperature100
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-40
IP RatingIP69K, IP68
Reverse Polarity ProtectionYes
Mounting TypeQuasi-flush
Thread SizeM18 x 1
Terminal TypeCable
Housing MaterialStainless Steel
Body StyleCylindrical
ManufacturerSick
Shape
Series
Hazardous Area Certification
Standards/Approvals
BrandSick
Supply Voltage DC Max30 V
Application
Communication InterfaceIO-Link
Sensing Distance8 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length50
Switching Frequency Max1 kHz
Dimensions
Width18
Electrical ConnectionCable
