Technical Reference

Technical Specifications

AttributeValue
Sensor TechnologyInductive
IP RatingIP68 - dust tight; water submersion protected, IP69K - dust tight; close-range high-pressure hot water protected
Minimum Operating Temperature-40 °C
Maximum Operating Temperature100 °C
ShieldingUnshielded
Reverse Polarity ProtectionYes
Output TypePNP
Standards MetcULus Certified, CE Marked
Thread SizeM18
Terminal Type3-Wire 2 m Cable
Mounting TypeNon-Flush
Housing MaterialStainless Steel
Body StyleBarrel
Material DetectedMetal
BrandSick
Detection Type
Switching Mode
Light Source
Hazardous Area Certification
Maximum Detection Range12 mm
Minimum Detection Range0 mm
Maximum DC Supply Voltage30 V
Minimum DC Supply Voltage10 V
Maximum AC output current200 mA
Electrical ConnectionCable
DimensionsM18 x 40 mm
Length40 mm
