Technical Reference

Technical Specifications

AttributeValue
Sensor TechnologyInductive
IP RatingIP68 - dust tight; water submersion protected, IP69K - dust tight; close-range high-pressure hot water protected
Minimum Operating Temperature-40 °C
Maximum Operating Temperature100 °C
ShieldingUnshielded
Reverse Polarity ProtectionYes
Output TypePNP
Standards MetcULus Certified, EN 60947-5-2, CE Marked, EN 60529
Thread SizeM30
Terminal Type3-Wire 2 m Cable
Mounting TypeNon-Flush
Housing MaterialStainless Steel
Body StyleBarrel
Material DetectedMetal
BrandSick
Detection Type
Switching Mode
Light Source
Hazardous Area Certification
Maximum Detection Range20 mm
Minimum Detection Range0 mm
Maximum DC Supply Voltage30 V
Minimum DC Supply Voltage10 V
Maximum AC output current200 mA
Electrical ConnectionCable
DimensionsM30 x 60 mm
Length60 mm
