Technical Specifications

AttributeValue
Supply Voltage10 V to 30 V
Output TypePNP NO
Maximum Operating Temperature100 °C
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-40 °C
IP RatingIP69K, IP68
Reverse Polarity ProtectionYes
Mounting TypeNon-flush
Thread SizeM30 x 1.5
Terminal TypeCable
Housing MaterialStainless Steel
Body StyleCylindrical
ManufacturerSick
Shape
Series
Hazardous Area Certification
Standards/Approvals
BrandSick
Supply Voltage DC Max30 V
Application
Communication InterfaceIO-Link
Sensing Distance20 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length70 mm
Switching Frequency Max0.5 kHz
Dimensions
Width30 mm
Electrical ConnectionCable
