Technical Reference

Technical Specifications

AttributeValue
Thread SizeM8
Terminal Type3-Pin M8 Connector
Mounting TypeFlush
Housing MaterialMetal
Body StyleBarrel
Standards MetcULus Listed, EN 60947-5-2, CE Marked
Sensor TechnologyInductive
IP RatingIP67 - dust tight; water immersion protected
Minimum Operating Temperature-25 °C
Maximum Operating Temperature75 °C
ShieldingShielded
Reverse Polarity ProtectionYes
Output TypeNPN
Material DetectedMetal
BrandSick
Detection Type
Switching Mode
Light Source
Hazardous Area Certification
Maximum Detection Range2 mm
Minimum Detection Range0 mm
Maximum DC Supply Voltage30 V
Minimum DC Supply Voltage10 V
Maximum AC output current200 mA
Electrical ConnectionConnector
DimensionsM8 x 50 mm
Length50 mm
Series
