Technical Reference

Technical Specifications

AttributeValue
Supply Voltage10 V to 30 V
Output TypePNP NC
Maximum Operating Temperature75 °C
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25 °C
IP RatingIP67
Reverse Polarity ProtectionYes
Mounting TypeNon-flush
Thread SizeM8 x 1
Terminal TypeCable
Housing MaterialMetal
Body StyleCylindrical
ManufacturerSick
Shape
Series
Hazardous Area Certification
Standards/Approvals
BrandSick
Supply Voltage DC Max30 V
Application
Communication Interface
Sensing Distance6 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length52 mm
Switching Frequency Max0.5 kHz
Dimensions
Width8 mm
Electrical ConnectionCable
