Technical Reference

Technical Specifications

AttributeValue
Supply Voltage10 V to 30 V
Output TypeNO
Maximum Operating Temperature75 °C
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25 °C
IP RatingIP67
Reverse Polarity ProtectionYes
Mounting TypeFlush
Thread SizeM12 x 1
Terminal Type2m Cable, 2-Wire
Housing MaterialMetal
Body StyleCylindrical
ManufacturerSick
Shape
Series
Hazardous Area Certification
Standards/Approvals
BrandSick
Supply Voltage DC Max30 V
Application
Communication Interface
Sensing Distance4 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current100 mA
Short Circuit Overload ProtectionYes
Length44 mm
Switching Frequency Max2 kHz
Dimensions
Width12 mm
Electrical Connection2-Wire, 2 m Cable
