Technical Reference

Technical Specifications

AttributeValue
Supply Voltage10 V to 30 V
Output TypeNPN NO
Maximum Operating Temperature75 °C
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25 °C
IP RatingIP67
Reverse Polarity ProtectionYes
Mounting TypeFlush
Thread SizeM30 x 1.5
Terminal Type2m Cable, 3-Wire
Housing MaterialMetal
Body StyleCylindrical
ManufacturerSick
Shape
Series
Hazardous Area Certification
Standards/Approvals
BrandSick
Supply Voltage DC Max30 V
Application
Communication Interface
Sensing Distance15 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length70 mm
Switching Frequency Max0.5 kHz
Dimensions
Width30 mm
Electrical Connection3-Wire, 2 m Cable
