Technical Reference

Technical Specifications

AttributeValue
Sensor TechnologyInductive
IP RatingIP68 - dust tight; water submersion protected, IP69K - dust tight; close-range high-pressure hot water protected
Minimum Operating Temperature-40 °C
Maximum Operating Temperature100 °C
ShieldingUnshielded
Reverse Polarity ProtectionYes
Output TypePNP
Standards MetUL Certified, FDA Approved, cULus Listed, EN 60947-5-2, CE Marked
Thread SizeM30
Terminal Type4-Pin M12 Connector
Mounting TypeFlush
Housing MaterialStainless Steel
Body StyleBarrel
Material DetectedMetal
BrandSick
Detection Type
Switching Mode
Light Source
Hazardous Area Certification
Maximum Detection Range15 mm
Minimum Detection Range0 mm
Maximum DC Supply Voltage30 V
Minimum DC Supply Voltage10 V
Maximum AC output current200 mA
Electrical ConnectionConnector
DimensionsM30 x 70 mm
Length70 mm
Depth45 mm
Series
