Technical Reference

Technical Specifications

AttributeValue
Sensor TechnologyInductive
IP RatingIP68 - dust tight; water submersion protected, IP69K - dust tight; close-range high-pressure hot water protected
Minimum Operating Temperature-25 °C
Maximum Operating Temperature75 °C
ShieldingShielded
Reverse Polarity ProtectionYes
Output TypePNP
Thread SizeM12
Terminal Type3-Wire 2 m Cable
Mounting TypeFlush
Housing MaterialStainless Steel
Body StyleBarrel
Standards MetUL Certified, FDA Approved, cULus Listed, EN 60947-5-2, CE Marked
Material DetectedMetal
BrandSick
Detection Type
Switching Mode
Light Source
Hazardous Area Certification
Maximum Detection Range4 mm
Minimum Detection Range0 mm
Maximum DC Supply Voltage30 V
Minimum DC Supply Voltage10 V
Maximum AC output current200 mA
Electrical ConnectionCable
DimensionsM12 x 58.8 mm
Length58.8 mm
Depth25 mm
Series
