Technical Reference

Technical Specifications

AttributeValue
Supply Voltage10 V to 30 V
Output TypeNPN NC
Maximum Operating Temperature70
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25
IP RatingIP67
Reverse Polarity Protection
Mounting TypeFlush
Thread Size
Terminal TypeAxial Plug
Housing MaterialPlastic
Body StyleRectangular
ManufacturerSick
Shape
Series
Depth30
Hazardous Area Certification
Standards/Approvals
BrandSick
Supply Voltage DC Max30 V
Application
Communication Interface
Sensing Distance3 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current100 mA
Short Circuit Overload ProtectionYes
Length6
Switching Frequency Max1 kHz
Dimensions6 x 10 x 30 mm
Width10
Electrical ConnectionAxial Plug
