Technical Reference

Technical Specifications

AttributeValue
Mounting TypeFlush
Thread Size
Terminal TypeAxial Plug
Housing MaterialPlastic
Body StyleRectangular
Supply Voltage10 V to 30 V
Output TypePNP NO
Maximum Operating Temperature75
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25
IP RatingIP67, IP68
Reverse Polarity ProtectionYes
ManufacturerSick
Shape
Series
Depth40
Hazardous Area Certification
Standards/Approvals
BrandSick
Supply Voltage DC Max30 V
Application
Communication Interface
Sensing Distance2 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length8
Switching Frequency Max2 kHz
Dimensions8 x 8 x 40 mm
Width8
Electrical ConnectionAxial Plug
