Technical Reference

Technical Specifications

AttributeValue
Mounting TypeFlush
Thread Size
Terminal TypeAxial Plug
Housing MaterialPlastic
Body StyleRectangular
Supply Voltage10 V to 30 V
Output TypeNPN NC
Maximum Operating Temperature75 °C
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25 °C
IP RatingIP68
Reverse Polarity ProtectionYes
ManufacturerSick
Shape
Series
Depth28 mm
Hazardous Area Certification
Standards/Approvals
BrandSick
Supply Voltage DC Max30 V
Application
Communication Interface
Sensing Distance3 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length16 mm
Switching Frequency Max2 kHz
Dimensions16 x 10 x 28 mm
Width10 mm
Electrical ConnectionAxial Plug
