Technical Specifications

AttributeValue
Supply Voltage10 V to 30 V
Output TypeNPN NC
Maximum Operating Temperature75 °C
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25 °C
IP RatingIP68
Reverse Polarity ProtectionYes
Mounting TypeNon-flush
Thread Size
Terminal Type4-Pin M12 Connector
Housing MaterialPlastic
Body StyleRectangular
ManufacturerSick
Shape
Series
Depth40 mm
Hazardous Area Certification
Standards/Approvals
BrandSick
Supply Voltage DC Max30 V
Application
Communication Interface
Sensing Distance8 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length26 mm
Switching Frequency Max2 kHz
Dimensions26 x 12 x 40 mm
Width12 mm
Electrical Connection4-Pin M12 Connector
