Technical Specifications

AttributeValue
Sensor TechnologyInductive
IP RatingIP68 - dust tight; water submersion protected
Minimum Operating Temperature-25 °C
Maximum Operating Temperature75 °C
ShieldingUnshielded
Reverse Polarity ProtectionYes
Output TypePNP
Thread SizeM8
Terminal Type3-Pin M8 Connector
Mounting TypeNon-Flush
Housing MaterialPlastic
Body StyleRectangular
Standards MetUL Certified, CE Marked
Material DetectedMetal
BrandSick
Detection Type
Switching Mode
Light Source
Hazardous Area Certification
Maximum Detection Range8 mm
Minimum Detection Range0 mm
Maximum DC Supply Voltage30 V
Minimum DC Supply Voltage10 V
Maximum AC output current200 mA
Electrical ConnectionConnector
Dimensions12 x 40 x 26 mm
Length12 mm
Depth40 mm
Height26 mm
SeriesIQB
