Technical Reference

Technical Specifications

AttributeValue
Mounting TypeFlush
Thread Size
Terminal Type4-Pin M12 Connector
Housing MaterialMetal
Body StyleRectangular
Supply Voltage10 V to 30 V
Output TypePNP NO
Maximum Operating Temperature70 °C
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25 °C
IP RatingIP67
Reverse Polarity ProtectionYes
ManufacturerSick
Shape
Series
Depth32 mm
Hazardous Area Certification
Standards/Approvals
BrandSick
Supply Voltage DC Max30 V
Application
Communication Interface
Sensing Distance7 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length8 mm
Switching Frequency Max0.15 kHz
Dimensions8 x 20 x 32 mm
Width20 mm
Electrical Connection4-Pin M12 Connector
