Technical Reference

Technical Specifications

AttributeValue
Supply Voltage10 V to 36 V
Output TypePNP NO/NC
Maximum Operating Temperature80 °C
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25 °C
IP RatingIP65
Reverse Polarity ProtectionYes
Mounting TypeNon-flush
Thread Size
Terminal Type4-Pin M12 Connector
Housing MaterialPlastic
Body StyleRectangular
ManufacturerSick
Shape
Series
Depth105 mm
Hazardous Area Certification
Standards/Approvals
BrandSick
Supply Voltage DC Max36 V
Application
Communication Interface
Sensing Distance60 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current250 mA
Short Circuit Overload ProtectionYes
Length40 mm
Switching Frequency Max0.1 kHz
Dimensions40 x 80 x 105 mm
Width80 mm
Electrical Connection4-Pin M12 Connector
