Technical Reference

Technical Specifications

AttributeValue
Mounting TypeFlush
Thread SizeM8 x 1
Terminal Type2m Cable, 3-Wire
Housing MaterialNickel Plated Brass
Body StyleCylindrical
Supply Voltage10 V to 30 V
Output TypePNP
Maximum Operating Temperature75 °C
Sensor TechnologyInductive
ShieldingShielded
Minimum Operating Temperature-25 °C
IP RatingIP67
Reverse Polarity ProtectionYes
ManufacturerSick
Shape
Series
Hazardous Area Certification
Standards/ApprovalscULus Listed, CE Certified
BrandSick
Supply Voltage DC Max30 V
Application
Communication Interface
Sensing Distance3 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current10 mA
Short Circuit Overload ProtectionYes
Length52 mm
Switching Frequency Max1 kHz
Dimensions
Width8 mm
Electrical Connection3-Wire, 2 m Cable
