Technical Reference

Technical Specifications

AttributeValue
Supply Voltage10 V to 30 V
Output TypePNP
Maximum Operating Temperature75
Sensor TechnologyInductive
ShieldingShielded
Minimum Operating Temperature-25
IP RatingIP67
Reverse Polarity ProtectionYes
Mounting TypeNon-flush
Thread SizeM12 x 1
Terminal Type2-Pin Connector
Housing MaterialNickel Plated Brass
Body StyleCylindrical
ManufacturerSick
Shape
Series
Hazardous Area Certification
Standards/ApprovalscULus Listed, CE Certified
BrandSick
Supply Voltage DC Max30 V
Application
Communication Interface
Sensing Distance10 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current10 mA
Short Circuit Overload ProtectionYes
Length46
Switching Frequency Max0.4 kHz
Dimensions
Width12
Electrical Connection2-Pin Connector
