Technical Reference

Technical Specifications

AttributeValue
Mounting TypeFlush
Thread SizeM30 x 1.5
Terminal Type4-Pin Connector
Housing MaterialNickel Plated Brass
Body StyleCylindrical
Supply Voltage10 V to 30 V
Output TypePNP
Maximum Operating Temperature75
Sensor TechnologyInductive
ShieldingShielded
Minimum Operating Temperature-25
IP RatingIP67
Reverse Polarity ProtectionYes
ManufacturerSick
Shape
Series
Hazardous Area Certification
Standards/ApprovalscULus Listed, CE Certified
BrandSick
Supply Voltage DC Max30 V
Application
Communication Interface
Sensing Distance20 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current10 mA
Short Circuit Overload ProtectionYes
Length71
Switching Frequency Max0.2 kHz
Dimensions
Width30
Electrical Connection4-Pin Connector
