Technical Reference

Technical Specifications

AttributeValue
Sensor TechnologyInductive
IP RatingIP68 - dust tight; water submersion protected
Minimum Operating Temperature-30 °C
Maximum Operating Temperature85 °C
ShieldingN/A
Reverse Polarity ProtectionYes
Output TypePNP
Standards MetUL Certified, CE Marked
Thread SizeM12
Terminal Type4-Pin M12 Male Connector
Mounting Type
Housing MaterialPlastic
Body StyleRectangular
Material DetectedMetal
BrandSick
Detection Type
Switching Mode
Light Source
Hazardous Area Certification
Maximum Detection Range45 mm
Minimum Detection Range0 mm
Maximum DC Supply Voltage30 V
Minimum DC Supply Voltage10 V
Electrical ConnectionConnector
Dimensions40 x 65 x 40 mm
Length40 mm
Depth65 mm
Height40 mm
SeriesIMR
