Technical Reference

Technical Specifications

AttributeValue
Mounting TypeFlush
Thread SizeM12 x 1
Terminal TypeCable
Housing MaterialStainless Steel
Body StyleCylindrical
Supply Voltage10 V to 30 V
Output TypePNP
Maximum Operating Temperature100
Sensor TechnologyInductive
ShieldingUnshielded
Minimum Operating Temperature-40
IP RatingIP69K, IP68
Reverse Polarity ProtectionYes
ManufacturerSick
Shape
Series
Hazardous Area Certification
Standards/ApprovalsCE, cULus, EN 60529, EN 60947-5-2 Certified
BrandSick
Supply Voltage DC Max30 V
Application
Communication InterfaceIO-LINK
Sensing Distance4 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length45
Switching Frequency Max2 kHz
Dimensions
Electrical ConnectionCable
