Technical Reference

Technical Specifications

AttributeValue
Supply Voltage10 V to 30 V
Output TypePNP
Maximum Operating Temperature75
Sensor TechnologyInductive
ShieldingUnshielded
Minimum Operating Temperature-40
IP RatingIP69K, IP68
Reverse Polarity ProtectionYes
Mounting TypeFlush
Thread SizeM30 x 1.5
Terminal Type4-Pin M12 Connector
Housing MaterialStainless Steel
Body StyleCylindrical
ManufacturerSick
Shape
Series
Hazardous Area Certification
Standards/ApprovalsCE, cULus, EN 60529, EN 60947-5-2 Certified
BrandSick
Supply Voltage DC Max30 V
Application
Communication InterfaceIO-LINK
Sensing Distance15 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length70.2
Switching Frequency Max0.2 kHz
Dimensions
Electrical Connection4-Pin M12 Connector
