Technical Reference

Technical Specifications

AttributeValue
Mounting TypeFlush
Thread Size
Terminal Type4-Pin M12 Connector
Housing MaterialPlastic
Body StyleRectangular
Supply Voltage10 V to 30 V
Output TypePNP
Maximum Operating Temperature75 °C
Sensor TechnologyInductive
ShieldingShielded
Minimum Operating Temperature-25 °C
IP RatingIP67, IP68
Reverse Polarity ProtectionYes
ManufacturerSick
Shape
Series
Depth8 mm
Hazardous Area Certification
Standards/Approvals
BrandSick
Supply Voltage DC Max30 V
Application
Communication Interface
Sensing Distance2 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length40 mm
Switching Frequency Max2 kHz
Dimensions40 x 8.1 x 8 mm
Width8.1 mm
Electrical Connection4-Pin M12 Connector
