Please note: Some technical details are unavailable for this product

Technical Specifications

AttributeValue
Mounting TypeNon-flush
Thread SizeM12 x 1
Terminal Type4-Pin M12 Connector
Housing MaterialV4A, Stainless Steel
Body StyleCylindrical
Supply Voltage10 V to 30 V
Output TypePNP
Maximum Operating Temperature100
Sensor TechnologyInductive
ShieldingUnshielded
Minimum Operating Temperature-40
IP RatingIP69K, IP68
Reverse Polarity ProtectionYes
ManufacturerSick
Shape
Series
Hazardous Area Certification
Standards/ApprovalsUL E181493, FDA, cULus Listed, CE Certified, EN 60947-5-2
BrandSick
Supply Voltage DC Max30 V
Application
Communication Interface
Sensing Distance8 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length65
Switching Frequency Max2 kHz
Dimensions
Electrical Connection4-Pin M12 Connector
